脈沖布袋除塵器 ：

Pulse bag filter:

工作原理 ：含塵氣體通過進風口進入中箱，大顆粒粉塵直接落入塵灰室。細小的煙塵通過除塵器布袋的過濾，被阻擋在布袋外表面，而凈化后的空氣則通過布袋進入凈氣室，并通過引風機排入大氣。脈沖除塵器通過脈沖噴吹技術實現高效除塵，當濾袋上的粉塵層增厚到一定程度時，控制系統會啟動清灰裝置，通過脈沖閥噴吹壓縮空氣，使濾袋迅速膨脹并抖落附著的粉塵，從而恢復其過濾性能。

Working principle: Dust containing gas enters the middle box through the air inlet, and large particles of dust directly fall into the dust chamber. The fine smoke and dust are filtered by the dust collector bag and blocked on the outer surface of the bag, while the purified air enters the clean air chamber through the bag and is discharged into the atmosphere through the induced draft fan. The pulse dust collector achieves efficient dust removal through pulse blowing technology. When the dust layer on the filter bag thickens to a certain extent, the control system will activate the dust cleaning device. Compressed air is blown through the pulse valve to rapidly expand the filter bag and shake off the attached dust, thereby restoring its filtering performance.

化工廠車間除塵設備 ：

Dust removal equipment in chemical plant workshop:

工作原理 ：含塵氣體首先進入膨脹灰斗進行預收集，然后通過導流板均勻分布在濾袋之間，灰塵殘留在濾袋外表面。為了保持設備阻力在合理范圍內，高壓氣體通過電磁閥產生脈沖射流，使壓縮空氣從噴口噴出，并通過里管引入濾袋，在瞬間迅速膨脹并抖落灰塵，實現除塵目的。設備采用微機自動控制裝置，可根據粉塵情況調整除塵周期和脈沖噴射時間。

Working principle: The dusty gas first enters the expansion ash hopper for pre collection, and then is evenly distributed between the filter bags through the guide plate, leaving dust residue on the outer surface of the filter bags. In order to maintain the resistance of the equipment within a reasonable range, high-pressure gas generates a pulse jet through an electromagnetic valve, causing compressed air to be sprayed out from the nozzle and introduced into the filter bag through the inner pipe, rapidly expanding and shaking off dust in an instant, achieving the purpose of dust removal. The equipment adopts a microcomputer automatic control device, which can adjust the dust removal cycle and pulse spraying time according to the dust situation.

破碎車間除塵器 ：

Dust collector in crushing workshop:

工作原理 ：粉塵在進入除塵設備后，通過物理或化學方式與氣體分離，然后被收集起來。凈化后的氣體被排放到大氣中。具體工作原理因不同除塵設備而異，但總體流程包括分離、收集和排放三個步驟。

Working principle: After entering the dust removal equipment, dust is separated from gas through physical or chemical means and then collected. The purified gas is discharged into the atmosphere. The specific working principle varies depending on different dust removal equipment, but the overall process includes three steps: separation, collection, and discharge.

碳素廠除塵器 ：

Carbon plant dust collector:

工作原理 ：含塵氣體在引風機引力作用下由進風口切向進入除塵器底部的灰斗，大顆粒粉塵首先落入灰斗，細小粉塵則通過布袋過濾，附著在布袋外表面。凈化后的氣體穿過布袋進入上箱體，由引風機引出并排入大氣。隨著粉塵的聚集，布袋表面的粉塵不斷增加，達到一定密集度時，控制系統中的PLC會啟動清灰程序，通過氣缸和離線閥的切換，進行脈沖噴吹清灰，使粉塵剝落并落入灰斗內。

Working principle: Dust containing gas enters the ash hopper at the bottom of the dust collector tangentially through the air inlet under the gravity of the induced draft fan. Large particles of dust first fall into the ash hopper, while small particles are filtered through the bag and attached to the outer surface of the bag. The purified gas passes through the bag and enters the upper box, which is then drawn out by the induced draft fan and discharged into the atmosphere. With the accumulation of dust, the dust on the surface of the bag continues to increase. When it reaches a certain density, the PLC in the control system will start the dust cleaning program. By switching between the cylinder and offline valve, pulse blowing is carried out to clean the dust, causing the dust to peel off and fall into the ash hopper.

打磨車間除塵器 ：

Dust collector in polishing workshop:

工作原理 ：利用負壓原理，通過吸風裝置將車間空氣中的粉塵顆粒吸入除塵器內部。高精度的布袋過濾系統將細微塵埃攔截，只允許潔凈空氣排出，帶來寧靜與清新。

Working principle: Using the negative pressure principle, the dust particles in the workshop air are sucked into the dust collector through the suction device. The high-precision bag filter system intercepts fine dust and only allows clean air to be discharged, bringing tranquility and freshness.

橡膠廠除塵器 ：

Rubber factory dust collector:

工作原理 ：含塵氣體由進風道進入灰斗，粗塵粒直接落入灰斗底部，細塵粒隨氣流轉折向上進入中、下箱體，積附在濾袋外表面。過濾后的氣體進入上箱體至凈氣集合管，經排風機排至大氣。清灰過程通過脈沖閥用壓縮空氣進行脈沖噴吹，使濾袋上的粉塵剝離并沉降至灰斗，確保濾袋清灰徹底。

Working principle: Dust containing gas enters the ash hopper through the air inlet duct. Coarse dust particles directly fall into the bottom of the ash hopper, while fine dust particles enter the middle and lower boxes upward with the airflow and accumulate on the outer surface of the filter bag. The filtered gas enters the upper box to the clean gas collection pipe, and is discharged to the atmosphere through the exhaust fan. The dust cleaning process is carried out by pulse blowing compressed air through a pulse valve, causing the dust on the filter bag to peel off and settle into the ash hopper, ensuring thorough cleaning of the filter bag.

單機除塵器 ：

Single machine dust collector:

工作原理 ：含塵氣體被吸入除塵器箱體內部，粗顆粒粉塵由于重力作用直接落入集塵器，微粒粉塵被濾袋捕集。經過濾袋過濾的潔凈氣體進入潔凈室，最后由風機從出風口排出。清灰過程通過脈沖閥噴吹壓縮空氣，使濾袋迅速膨脹并抖落粉塵，然后恢復過濾狀態。

Working principle: The dusty gas is sucked into the interior of the dust collector box, and the coarse particle dust falls directly into the dust collector due to gravity. The fine particle dust is captured by the filter bag. The clean gas filtered by the filter bag enters the clean room and is finally discharged from the air outlet by the fan. The dust cleaning process uses a pulse valve to blow compressed air, causing the filter bag to rapidly expand and shake off dust, and then restore the filtering state.

這些除塵設備雖然應用場合和具體結構有所不同，但總體工作原理均包括過濾、清灰和排放三個核心步驟，通過不同的技術手段實現車間內粉塵的有效去除和凈化。

Although these dust removal devices have different applications and specific structures, their overall working principle includes three core steps: filtration, dust cleaning, and emission. Through different technical means, effective removal and purification of dust in the workshop are achieved.
